Piston single stage high pressure regulator - S400
S400 high pressure cylinder regulator is particularly suited for put vessels under pressure, leak detection and purge of pipe work. A cylinder connector is necessary to connect it to the cylinder valve.
Key advantages
  • Decompresses the downstream regulation system by turning the handwheel counter-clockwise
  • Accurate pressure control for reliable service
  • Connection available for relief valve
  • Panel mouting possible due to the rear threads
  • Can be equipped with a shut off valve at the outlet

FLOW CURVES

Product image

Specifications
Female ports16 x 1.336 (inlet) - G3/8 (outlet) or 1/4 NPT (inlet/outlet)
Seat sealPCTFE
O-ringNBR / EPDM (standard) / FPM
Piston AISI 316L
Weight+/- 1,6 kg
Leak rate10-8 M bar l/s
Temperature range-20 to +60 °c
GaugesHigh and low pressure (M10 x 1 or 1/4 NPT)
Inlet pressure300 bar
Outlet Pressure200 bar
Nominal flow30 Nm3/h (n2)
Oxygen useBrass only
Product Configurator

Body material
Safety relief valve configuration

End connections
O-ring material
Gauges
S
L
-
400
16
NBR
1

Chrome plated brass
L
Stainless steel
I
With decompression system
-
With a safety valve connection available
S

16 x 1.336 - G3/8
16
1/4 NPT - 1/4 NPT
N
NBR
NBR
EPDM - Standard
EPDM
FPM
FPM
With
1
